Now go reread what I wrote and try it.


iamtherealJayy

Full Access Member
Joined
Nov 26, 2021
Posts
1,588
Reaction score
277
Location
Tennessee
First Name
Jacob
Truck Year
1987, 1978, 1976
Truck Model
V20, K10, K10
Engine Size
350, 350, 350
Here’s videos from this morning.
xc_hide_links_from_guests_guests_error_hide_media
xc_hide_links_from_guests_guests_error_hide_media
xc_hide_links_from_guests_guests_error_hide_media
In the second video with the revs you can hear when I quickly wot it tries to die if I stay in it it will shake and sputter and eventuslly bring the rpm up. In the driving video I was laying into the throttle in the long straight, up hills it doesn’t seem like it wants to go much faster. My speedometer is off, it’s at about 100 when I’m sitting still so 0 is roughly 45. I showed the speedo at around 15 which would be around 60.


AuroraGirl

Full Access Member
Joined
Sep 8, 2019
Posts
9,693
Reaction score
6,875
Location
Northern Wisconsin
First Name
Taylor
Truck Year
1978, 1980
Truck Model
K10, K25
Engine Size
400(?), 350
Here’s videos from this morning.
xc_hide_links_from_guests_guests_error_hide_media
xc_hide_links_from_guests_guests_error_hide_media
xc_hide_links_from_guests_guests_error_hide_media
In the second video with the revs you can hear when I quickly wot it tries to die if I stay in it it will shake and sputter and eventuslly bring the rpm up. In the driving video I was laying into the throttle in the long straight, up hills it doesn’t seem like it wants to go much faster. My speedometer is off, it’s at about 100 when I’m sitting still so 0 is roughly 45. I showed the speedo at around 15 which would be around 60.
sounds rich or the advance isnt where it needs to be.


iamtherealJayy

Full Access Member
Joined
Nov 26, 2021
Posts
1,588
Reaction score
277
Location
Tennessee
First Name
Jacob
Truck Year
1987, 1978, 1976
Truck Model
V20, K10, K10
Engine Size
350, 350, 350
In which part? I leaned it some since I played with the timing. I did about a quarter turn in on each screw


iamtherealJayy

Full Access Member
Joined
Nov 26, 2021
Posts
1,588
Reaction score
277
Location
Tennessee
First Name
Jacob
Truck Year
1987, 1978, 1976
Truck Model
V20, K10, K10
Engine Size
350, 350, 350
How would I adjust the off idle mix? Metering rods and jets?


AuroraGirl

Full Access Member
Joined
Sep 8, 2019
Posts
9,693
Reaction score
6,875
Location
Northern Wisconsin
First Name
Taylor
Truck Year
1978, 1980
Truck Model
K10, K25
Engine Size
400(?), 350
xc_hide_links_from_guests_guests_error_hide_media
what hole on the accelerator pump lever is the linkage in? the one closests to the top of the carb is more aggressive and the furthest is least. I believe they come placed in the center.
You must be registered for see images attach

here is an old pic of mine, on the center(look at the brass linkage running from the throttle lever up to the top of the carb, its 3 circles with the link in the center of the 3) You may try the lower one if you wanted


iamtherealJayy

Full Access Member
Joined
Nov 26, 2021
Posts
1,588
Reaction score
277
Location
Tennessee
First Name
Jacob
Truck Year
1987, 1978, 1976
Truck Model
V20, K10, K10
Engine Size
350, 350, 350
I believe the accelerator is still in the middle I haven’t changed it. If I set it to the least would that effect the secondaries as well? I’d invest in an afr gauge but that’s a lot of work for my current exhaust it just doesn’t make it worth it.


Rusty Nail

Full Access Member
Joined
Jan 29, 2015
Posts
10,041
Reaction score
10,138
Location
the other side of the internet
First Name
Rusty
Truck Year
1977
Truck Model
C20
Engine Size
350sbc
Dude.
You are overflowing with questions.
Rather than guess what the settings are, take my advice and go look at it. You will likely be surprised to see you may find answers.

Don't try to skip ahead. Auto mechanics is slow and steady - one thing at a time, in my experience.
Getcha a pair of blinders and put.them.on.

That's good advice.


Horses wear blinders to reduce their field of vision and stay focused on their tasks. When pulling loads or racing, horses are easily distracted. Horses that pull wagons in cities need blinders to keep their attention focused straight ahead and block out the distractions around them.


iamtherealJayy

Full Access Member
Joined
Nov 26, 2021
Posts
1,588
Reaction score
277
Location
Tennessee
First Name
Jacob
Truck Year
1987, 1978, 1976
Truck Model
V20, K10, K10
Engine Size
350, 350, 350
I’ve had this carb apart before but I don’t remember the factory jet size or anything related, it’s all still factory settings. I’ll have to dig out the book and read up some. I agree I can’t concentrate on much of anything.


rich weyand

Full Access Member
Joined
May 28, 2014
Posts
967
Reaction score
177
Location
Bloomington Indiana
First Name
Rich
Truck Year
1978
Truck Model
K10
Engine Size
350
Vacuum advance on ported will always stumble on suddenly coming off idle. The vac cylinder needs time to synch up with manifold advance, which is where it should have been. Put the vacuum advance on manifold vacuum and retune.



Ricko1966

Full Access Member
Joined
Apr 11, 2017
Posts
5,602
Reaction score
9,124
Location
kansas
First Name
Rick
Truck Year
1975
Truck Model
c20
Engine Size
350
Vacuum advance on ported will always stumble on suddenly coming off idle. The vac cylinder needs time to synch up with manifold advance, which is where it should have been. Put the vacuum advance on manifold vacuum and retune.

Told him this post 5 again post 17 .let's see how many more posts before he tries it.


potent rodent

Full Access Member
Joined
Mar 22, 2020
Posts
195
Reaction score
112
Location
indiana
First Name
butch
Truck Year
86 and 78
Truck Model
1500
Engine Size
350 and 305
move your vac adv to full manifold vac and try and put your acc pump rod in the top hole for a quicker pump shot , timing is very important on sbc they like around 34 to 36 degrees of total timing
