V10 rear disc conversion

[Honky Kong jr]

Started my conversion. Im using 92 full size Blazer rotors with the hub mount opened up to fit the axles and using front caliper carriers with the centers machined to fit the backing plate lip. I would love to post pics but it keeps telling me they are to big and when i resize them they look like ass and not a good ass either. Any help with that would be great.



[1987 GMC Jimmy]

I tagged @Shaggy on another post where photos couldn't be uploaded, possibly for the same reason. I can upload some fine, but I just had to resize one, too. Here's a good write up on a rear disc conversion. I'm sure you've probably seen it by now, and they used Chevy Astro parts, but here you go anyways.

http://www.gmsquarebody.com/forum/showthread.php?t=1610&highlight=Rear+disc+brakes+cheap



[Honky Kong jr]

Yes i saw it thats for 2wd mines 4x4



[1987 GMC Jimmy]

Didn't the 2002 Astro get the six lug pattern to match that of a square 4x4?



[Honky Kong jr]

Yes. If these dumb pics would show up clear after resizing you could see how it all comes together. All GM parts and look as if it came that way with nice meaty rotors. When i built my Chevelle i used all 2nd gen S10 parts for the rear disc swap. Parts are easier to find that way.



[1987 GMC Jimmy]

Gotcha. I tagged Shaggy twice today so maybe he'll see it and offer feedback.



[Honky Kong jr]

Its just odd when i did my transfer case thread i just uploaded pics off my phone and now it tells me they are to big.



[1987 GMC Jimmy]

Same here for some of them. If it's a picture that I took, it seems to work fine. If it's a screenshot, I have to crop it because it tells me it's too big.



[Honky Kong jr]

Here is my brake swap using 92 fullsize Blazer front rotors with the centers machined to fit the axles. Also front caliper mounts mounted to the axle housing. I had the center opening machined to fit on the backing plate ledge for centering purposes. Works out pretty nice but i have to get longer studs. I have 28 and 30 spline axles but not sure which ones to use until i find either a spool or posi unit. I used the eaton i have up front.



[Honky Kong jr]

It will come all apart and get cleaned and painted.



[74 Shortbed]

Nice setup.
