NV3500 swap

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

eskimomann209

Full Access Member
Joined
Jan 9, 2019
Posts
1,849
Reaction score
2,005
Location
Modesto
First Name
Marcus
Truck Year
1973
Truck Model
C10
Engine Size
5.3

78C10BigTen

Full Access Member
Joined
Apr 12, 2017
Posts
15,948
Reaction score
25,339
Location
pennsylvannia
First Name
Ted
Truck Year
1978
Truck Model
C10 BIG TEN
Engine Size
350
Cool this thread came up as i just said about putting an nv3500 in my c10. Seems like id go with the mechanical slave.


87r-10

Junior Member
Joined
Sep 9, 2019
Posts
6
Reaction score
1
Location
Wisconsin
First Name
Tanner
Truck Year
1987
Truck Model
R-10
Engine Size
350
Cool this thread came up as i just said about putting an nv3500 in my c10. Seems like id go with the mechanical slave.
How would I change it to a manual slave?


bucket

Super Moderator
Staff member
Super Moderator
Joined
Aug 3, 2010
Posts
30,439
Reaction score
28,345
Location
Usually not in Ohio
First Name
Andy
Truck Year
'77, '78, '79, '84, '88
Truck Model
K5 thru K30
Engine Size
350-454
Hydraulic clutch is the bee's knees anyways...


87r-10

Junior Member
Joined
Sep 9, 2019
Posts
6
Reaction score
1
Location
Wisconsin
First Name
Tanner
Truck Year
1987
Truck Model
R-10
Engine Size
350
All NV3500 are hydraulic. They are either external or internal slave.
Okay yeah mines an external slave that I’m putting in but hoping my grandpa kept the slave cuz this is a low budget swap


87r-10

Junior Member
Joined
Sep 9, 2019
Posts
6
Reaction score
1
Location
Wisconsin
First Name
Tanner
Truck Year
1987
Truck Model
R-10
Engine Size
350
Does anyone know how long the push rod is for the slave cylinder? I lost mine and do not have the budget to buy a new slave


76c10rosedale

Junior Member
Joined
Aug 8, 2024
Posts
1
Reaction score
0
Location
Idaho
First Name
Brad
Truck Year
1976
Truck Model
C10
Engine Size
355
Geez every old guy in my town keeps telling me that using an s10 transmission is impossible and weaker. They all say the shifter will end up under the seat, even when provided photographic proof. Idk why i try, to them anything to do with touching a computer is "hacking"


bluex

Full Access Member
Joined
May 9, 2013
Posts
1,971
Reaction score
2,575
Location
Spartanburg SC
First Name
Paul
Truck Year
1978
Truck Model
C15
Engine Size
350
Geez every old guy in my town keeps telling me that using an s10 transmission is impossible and weaker. They all say the shifter will end up under the seat, even when provided photographic proof. Idk why i try, to them anything to do with touching a computer is "hacking"
There are 2 differences between a full size an a s10 nv3500. The S10 has a closer ratio gear set, and it uses a 700r4 output shaft size. Everything else is the same. Now like I mentioned in 98 or 99 the shifter did move back on the trans but I believe it did that on all models not just the s10. So technically a full size is stronger because it has the 4l80 size output but I believe the s10 trans is a better choice for a sport truck with it closer gear ratios. The 1-2 drop in a full size trans is pretty extreme.
