04 LM7 into 87 K5

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

K5Rob

Junior Member
Joined
Dec 1, 2024
Posts
19
Reaction score
1
Location
Maine
First Name
Rob
Truck Year
1987
Truck Model
K5 Blazer
Engine Size
350
Can anyone explain what they did to make their 4L60E work correctly with an NP208 ?? I have searched for weeks and can’t find anything. I know there are Several VSS options but when i dig a little deeper nothing seems to work correctly or put out the right signal. Which leads to poor performance, not shifting past 2nd gear, even no shifting. Is this why people scrap the 208 for a 241? Then of course the 4hi/low switch which seems a little more forgiving but I still am unclear on the tuning aspect - coming from a 2wd PCM would i need to source a 4wd pcm, or are the tables simply cut and paste for the tuner? Lastly I am assuming the factory shift linkage mates up to the 4L60E without too much hassle but I couldn’t find anything on this either. This is strictly for curiosity as i have decided to stick with the 700r4 for the above reasons.


Ricko1966

Full Access Member
Joined
Apr 11, 2017
Posts
5,566
Reaction score
9,016
Location
kansas
First Name
Rick
Truck Year
1975
Truck Model
c20
Engine Size
350
Yea, this gets into what every LS swapper faces... the issue with 60e/80e swapping is you NEED vss , and if 4x4 you'll need your hi/lo switch off the t case


The expensive solution (due to rarity) is to run a passengers side drop NP241 OR 208 from a 90 or 91 suburban , (maybe k5?)
Which has vss.

Then run a 90/91 burb/k30/k5 electronic speedo instrument cluster .


Optionally---

You can visit dakote digital for a adapter to turn the cable speedo output on your 208 to VSS .... ORD might have also, idk.



The 700r4 is the easiest, cheapest methos (go on fleabay and price a np241 or vss 208 and you'll see why)
IDK so throwing this out for someone who might shed some light. I'm pretty sure Camaros starting in 1984 used an adapter at the mechanical speedometer location that went in just like a mechanical drive but put out vss for electric speedo. Anyone,anyone,Bueller, Bucket.

Last edited:

Vbb199

B-rate Hillbilly Customs
Joined
Jan 12, 2018
Posts
9,098
Reaction score
15,435
Location
Salisbury NC
First Name
Vince
Truck Year
89, 79
Truck Model
89 Suburban R1500, 79 C10
Engine Size
350, 502


The adapter to give the PCM a speedo signal.

The pulses per revolution (a calculation based off of the number of teeth on the reluctor wheel inside your transfer case) is a programmable variable inside your P59 pcm.

As is the VSS pulses per mile, gear ratios, tire size and axle ratio.


Vbb199

B-rate Hillbilly Customs
Joined
Jan 12, 2018
Posts
9,098
Reaction score
15,435
Location
Salisbury NC
First Name
Vince
Truck Year
89, 79
Truck Model
89 Suburban R1500, 79 C10
Engine Size
350, 502
You must be registered for see images attach


Vbb199

B-rate Hillbilly Customs
Joined
Jan 12, 2018
Posts
9,098
Reaction score
15,435
Location
Salisbury NC
First Name
Vince
Truck Year
89, 79
Truck Model
89 Suburban R1500, 79 C10
Engine Size
350, 502
Then of course the 4hi/low switch which seems a little more forgiving but I still am unclear on the tuning aspect - coming from a 2wd PCM would i need to source a 4wd pcm, or are the tables simply cut and paste for the tuner?


the tables for 4x4 stuff should be in the PCM by default..

edit, i looked in the tune repository on HPtuners website, and a 2wd 04 truck does have the 4x4 stuff in it. you should be good. its not much thats really needed... its just torque calculations, the most important part is the VSS signal


Vbb199

B-rate Hillbilly Customs
Joined
Jan 12, 2018
Posts
9,098
Reaction score
15,435
Location
Salisbury NC
First Name
Vince
Truck Year
89, 79
Truck Model
89 Suburban R1500, 79 C10
Engine Size
350, 502
There is also a low 4x4 shift table ,

It tells the trans what mph to shift when in low 4x4.


K5Rob

Junior Member
Joined
Dec 1, 2024
Posts
19
Reaction score
1
Location
Maine
First Name
Rob
Truck Year
1987
Truck Model
K5 Blazer
Engine Size
350
There is also a low 4x4 shift table ,

It tells the trans what mph to shift when in low 4x4.
So if using the 4L60E and NP208, the PCM needs VSS from the transmission, transfer case or both?

Would I keep the factory VSS on the transmission plugged in and also add the Dakota Digital pulse generator at the transfer case cable input?


Vbb199

B-rate Hillbilly Customs
Joined
Jan 12, 2018
Posts
9,098
Reaction score
15,435
Location
Salisbury NC
First Name
Vince
Truck Year
89, 79
Truck Model
89 Suburban R1500, 79 C10
Engine Size
350, 502
So if using the 4L60E and NP208, the PCM needs VSS from the transmission, transfer case or both?

Would I keep the factory VSS on the transmission plugged in and also add the Dakota Digital pulse generator at the transfer case cable input?

If im not mistaken your 2004 2wd 60e has the vss output at the tailshaft housing.

You'll be removing that to mate the 208 to it.

THe pulse generator goes where the old speedo gear housing went on the 208


K5Rob

Junior Member
Joined
Dec 1, 2024
Posts
19
Reaction score
1
Location
Maine
First Name
Rob
Truck Year
1987
Truck Model
K5 Blazer
Engine Size
350
If im not mistaken your 2004 2wd 60e has the vss output at the tailshaft housing.
Yes it does, good call. So i am wondering now if i should keep the 4L60E or the 700r4


K5Rob

Junior Member
Joined
Dec 1, 2024
Posts
19
Reaction score
1
Location
Maine
First Name
Rob
Truck Year
1987
Truck Model
K5 Blazer
Engine Size
350
All i found when researching was problems getting the 4l60e to work correctly. Maybe just bad tuning?


CalSgt

Full Access Member
Joined
Oct 3, 2021
Posts
1,730
Reaction score
3,882
Location
CA
First Name
Casey
Truck Year
1980
Truck Model
Chevy K-10 Custom Deluxe
Engine Size
350
So if using the 4L60E and NP208, the PCM needs VSS from the transmission, transfer case or both?

Would I keep the factory VSS on the transmission plugged in and also add the Dakota Digital pulse generator at the transfer case cable input?
When I did my 4L60E + 208 combo all of the information I found claimed the Dakota signal wasn’t good enough for the factory PCM to shift correctly.

I ended up with a custom VSS and reluctor wheel from a 241 and modified my tail housing because I couldn’t find an adapter.

You must be registered for see images attach



Now there’s an adapter that mounts in the Speedo gear hole for like $150

https://www.walterseandp.com/product-page/np208-electronic-vss-conversion-kit-r2
